Dettagli del prodotto
Luogo di origine: SHENZHEN
Marca: HSCXLED
Certificazione: KC CE CE-LVD CE-EMC ROHS FCC CCC ISO9001
Numero di modello: P1.25/P1.5/P1.86/P2/P2.5
Termini di pagamento e di spedizione
Quantità di ordine minimo: 1SET
Imballaggi particolari: Cassa da combattimento/Cassa in legno/Cassa per fave di miele
Tempi di consegna: 18-25 giorni lavorativi
Capacità di alimentazione: 1000 set
Nome del prodotto: |
Display portatile a LED |
Specifica: |
Videowall, schermo LED, poster digitale |
Misurare: |
640*1920/960*1920 mm/Altro |
Luminosità: |
600-1000 (personalizzabile) |
Frequenza di aggiornamento: |
3840hz~7680hz |
Profondità di colore: |
14-16 bit |
Potenza massima/media: |
600/180 (W/m²) |
Temperatura operativa: |
-20℃~60℃ |
Confezione: |
Flight Case o custodia in legno |
Durata: |
Durata della vita≥100000H,MTBF ≥50000H |
CHIP LED: |
Nationstar/Kinglight/Hongshen |
Metodo di controllo: |
Controllo app, Controllo telefono cellulare, USB, Wifi |
Nome del prodotto: |
Display portatile a LED |
Specifica: |
Videowall, schermo LED, poster digitale |
Misurare: |
640*1920/960*1920 mm/Altro |
Luminosità: |
600-1000 (personalizzabile) |
Frequenza di aggiornamento: |
3840hz~7680hz |
Profondità di colore: |
14-16 bit |
Potenza massima/media: |
600/180 (W/m²) |
Temperatura operativa: |
-20℃~60℃ |
Confezione: |
Flight Case o custodia in legno |
Durata: |
Durata della vita≥100000H,MTBF ≥50000H |
CHIP LED: |
Nationstar/Kinglight/Hongshen |
Metodo di controllo: |
Controllo app, Controllo telefono cellulare, USB, Wifi |
Digital Led Poster Screen /Stand Poster Led Display
Plug-and-Play HD LED Display/Standing Poster LED Display
Retail Exhibitions Poster Display Screen
Portable LED Poster Display Stand Digital Signage
Indoor Display LED Poster Screen/Foldable Advertising Screen
![]()
LED Poster Display screen Specification:
| Poster LED display Specification | |||||
| Pixel Pitch(mm) | P1.25 | P1.53 | P1.86 | P2 | P2.5 |
| Pixel Matrix per sqm. |
640000 | 422500 | 288906 | 250000 | 160000 |
| Pixel Configuration |
1010 | 1010/1212 | 1515 | 1515 | 2020 |
| Scanning | 1/64 | 1/52 | 1/43 | 1/40 | 1/32 |
| Module Size | 320mmX160mm | ||||
| Brightness(nits) | 600-1000(Customizable) | ||||
| Power con. (Max/Avg) |
600W/150W | ||||
| Cabinet Dimension |
640mmX1920mm/1280mmX1920mm | ||||
| IP Rate | IP45 | ||||
| Working Temperatǔre |
-10~+50° | ||||
| front &Rear | Front | ||||
| Refresh Rate | 3840hz~7680hz | ||||
| Gray Scale(bit) | 14-16bits | ||||
| View Angle(H/V) | 140⁰±10°/160±10° | ||||
| Input Voltage(AC) | 110-220VAC/50Hz±10% | ||||
| Singal | DP1.4/DP1.2/HDMI/DVI/RGBHV/S-Video /Ypbpr(HDTV)~ | ||||
| Controller | Novastar/Linsn/Colorlight/Huidu/Mooncell/Xixun | ||||
![]()
LED poster display Introduction:
LED Poster Screen - Foldable LED Electronic Poster, is a flexible and portable LED display screen with the advantages of high brightness, high-definition display, and rich colors. Easy to store and fold design, equipped with universal wheels, the poster screen can be moved at any time, and it also has a lightweight and movable design, light weight, and can be easily carried by a single unit. At the same time, it also supports rapid splicing of multiple devices, and LED poster screens can achieve seamless splicing of multiple units, meeting the display needs of various sizes and shapes.
Digital Foldable LED Poster Display:
Compact & Portable-Folds to reduce volume by 50% optimizing storage and transport compared to traditional posters;when folded,it transforms into a double-sided screen,capable of displaying the same or different contents on each side.
The Die-casting Aluminum body make sure super thin and lightweight each panel,easier to move here and there for temporary occasions such as convention and exhibition centers, shopping centers,conference halls,weddings,performances,airports,stations,supermarkets,restaurants, photo studios,etc.
Ready to use:
No any installation needed-just unfold,then plug and play for instant operation.
With a flexible,magnetic detachable border and fast-lock splicing system,units can be seamlessly connected in just 5 minutes-much faster and smoother than traditional poster installations.
The use of aviation plug data port can realize the splicing of multiple screens,infinite splicing infinite possibilities.
The SMD lamp beads adopt the "tile level" GOB process, which is scratch resistant, anti drop,surface splash resistant, moisture-proof, and more stable to use.
The GOB LED module offers superior durability,damage resistance,and low maintenance,ensuring long-term reliability and extended lifespan.
The poster adopts hub connection design,and it will take 5 seconds only for replacement or maintenance,which greatly improves maintenance efficiency.
The base features a FUMA wheel and handle design for effortless mobility,enhanced convenience,and superior load-bearing capacity.
Wireless & Flexible Control:
Synchronous playback/Asynchronous Playback/USB flash drive playback/Cluster cloud playback/HDMI /Mobile Phone/Computer/LAN playback.
Multimedia information/pictures,etc.can be remotely released to the LED poster screen anytime and anywhere.
![]()
LED Poster display Product Description:
The HSCXLED intelligent LED screen solution is suitable for digital signage advertising displays in shopping malls, exhibition halls, and event venues. Suitable for various activities and rental occasions. Due to its portability and ease of installation, it can be quickly deployed and put into use. This Poster LED display combines the advantages of hardware and software, providing a multifunctional, high-definition, easy to operate and manage advertising display solution.
HSCXLED -Poster led display adopts a P1.25-P2.5MM pixel pitch and provides high-resolution display screen. The size is 80 inches (13.78 square feet), providing a large and clear visual experience. This high-resolution screen is perfect for displaying details and vivid images, making it suitable for various advertising and information purposes.
[ GOB Durable Technology ] Adopting GOB (Board Adhesive) technology to enhance the durability of LED digital signage display screens. This surface technology can protect the screen from environmental factors such as dust, moisture, and physical impact. It ensures that the poster led display screen maintains functionality and visual appeal even under harsh conditions, making it a reliable choice for long-term use in different indoor environments.
[ Portable and Mobile Design ] HSCXLED- LED poster display screen is easy to carry and move, with a floor standing foldable structure. It comes with a flight case for easy transportation and storage. This feature is particularly suitable for events and rentals as it allows for quick installation and removal, saving time and effort.
The LED poster screen supports seamless splicing, allowing multiple screens to be combined to form a larger display area. In addition, the plug and play feature makes it easy to operate. Users only need to connect to the screen to start displaying content, without the need for complex setup procedures.
Advanced control functions: HSCXLED-Poster led display includes a timer switch, split screen function, and publishing system. Timer switch can achieve automatic on/off plan, saving energy. The split screen function can display multiple contents simultaneously, increasing the screen's versatility. The publishing system facilitates remote content management and updates, allowing users to easily control the display of content remotely.
[ Wireless Connection ] With WiFi connection function, HSCXLED-poster LED display can achieve wireless content transmission and control. This feature enhances the convenience of using the screen, allowing users to easily update and manage display content remotely using mobile devices or computers. It also supports real-time updates to ensure that the displayed information is always up-to-date.
This LED poster screen has a wide viewing angle, allowing viewers to clearly see content from different positions. This function is very important in public places such as shopping malls, exhibition halls, and event venues where audiences can view screens from various angles. Wide angle viewing ensures that information is effectively conveyed to a wider audience without any visual distortion.
LED Electronic Poster Screen:Multiple models are available for selection, and multiple sizes can be customized, such as(Screen Size: 25.45inch x 77.82inch; Package Size: 48.03inch x 26.38inch x 29.53inch; Outline Dimension: 25.45inch x 17.72inch x 80.61inch; Module Size: 12.6inch x 6.3inch)Communication Method-APP/USB drive/Ethernet port/4G remote.And our poster LED display screen supports customized plugs for European and British standards, meeting the usage needs of different countries.
![]()
HSCXLED LED poster display advantage:
Up and down folding design (convenient for transportation, saving transportation costs);
Provide plugs according to customer requirements, and they can be used immediately after being powered on;
Content publishing can be done through mobile app/computer app/computer network cable/remote network control;
Up to 10 units can be cascaded to splice the entire screen, with HDMI cable cascading for plug and play functionality;
Supports synchronous and asynchronous operations, and can display videos/images/ppt/word, etc.
GOB process, moisture-proof, waterproof, and anti- collision.
Using the latest packaging technology, each LED point is consistent,
High quality, life time is more than 100,000 hours,
Stand Advertising LED display Specification:
LED poster display for Retail environment: In specialized stores and counters such as clothing and shoe cabinets, LED poster screens can be suspended in a fashionable and simple manner, eye-catching and fully enhancing the level of counters. In large-scale supermarket scenarios, supermarket information can be presented in a scrolling manner.
Poser screen for stores: LED poster screens can achieve intelligent, high-definition, and high brightness display of catering store brand background, product promotions, new product launches, and other information, comprehensively enhancing consumers' shopping experience.
Public places: In airports, stations, hospitals, schools and other places, LED poster screens can be used to publish schedules, notices, guidance information, etc., improving the efficiency of information acquisition.
Standing Poster Display for Cultural activities: In exhibition venues such as museums, exhibition halls, corporate exhibition halls, etc., LED poster screens can be used to display exhibition introductions, corporate promotions, product demonstrations, and other content. Dynamic display methods can better attract visitors' attention and enhance display effectiveness.
LED display screen for Digital cinema: Applied in digital cinema scenes, the intelligent display of multimedia information on LED poster screens, text and image rotation, real-time information push and other functional applications effectively enhance the in store experience of cinema users.
