Casa > prodotti > Esposizione di LED flessibile > LED Transparent Film Screen Flexible Transparent LED Screen

LED Transparent Film Screen Flexible Transparent LED Screen

Dettagli del prodotto

Luogo di origine: Cina Shenzhen

Marca: HSCXLED

Certificazione: KC CE ROHS FCC CCC ISO9001

Numero di modello: P6.25

Termini di pagamento e di spedizione

Quantità di ordine minimo: 1Set

Imballaggi particolari: Custodia in legno/scatola a nido d'ape/combattimento

Tempi di consegna: 10-15 giorni di lavoro

Termini di pagamento: L/C, T/T, D/A, D/P, Western Union, MoneyGram

Capacità di alimentazione: 1000set

Ottenga il migliore prezzo
Dettagli del prodotto
Evidenziare:

LED film screen

,

Transparent Led Display

,

Glass Film Crystal LED Display

Nome del prodotto:
Schermo del film trasparente a LED
Applicazione:
interno, esterno
Tipo:
schermo a led Film
Luce a LED:
SMD1515
Modello::
P6.25
Permeabilità:
90%~ 95%
Luminosità:
2000-4000
Tensione in ingresso:
AC110-240V50/ 60Hz
Potenza media:
200 W/m2
Durata:
100000 ore
Nome del prodotto:
Schermo del film trasparente a LED
Applicazione:
interno, esterno
Tipo:
schermo a led Film
Luce a LED:
SMD1515
Modello::
P6.25
Permeabilità:
90%~ 95%
Luminosità:
2000-4000
Tensione in ingresso:
AC110-240V50/ 60Hz
Potenza media:
200 W/m2
Durata:
100000 ore
Descrizione del prodotto
Indoor Transparent LED Film Screen PCB Board Flexible Soft Curved Curtain Transparent Led Screen
Transparent Led Film Full Color Screen Transparent Led Screen
Feature highlights:

This New Technology Indoor Transparent LED Film Screen offers high transparency up to 95%, making it ideal for glass curtain walls and retail environments. With a thin profile of just 2.5mm thickness, it supports versatile display functions including video, pictures, text, animation, and cartoons. The product ensures vibrant visuals with brightness levels of 2000/4000 CD/㎡ and a wide viewing angle of 160°. Certified with CCC, KC, CE ROHS FCC, it guarantees compliance with quality and safety standards, enhancing market access for buyers.



The core usage characteristics of LED film screen are light, thin, flexible, high transparency and invisibility, which can adapt to special carriers such as glass curtain walls, and balance display function with the original appearance of the building.

  • Lightweight and flexible LED display screen
  • Convenient installation of LED film screen
  • Modular splicing
  • High transmittance LED transparent screen

LED Transparent Film Screen Flexible Transparent LED Screen 0

Transparent LED Film Screen Application:
  • Advertising promotion: LED film screen supports multiple playback modes, playing videos, pictures, text and other advertising content to attract attention;
  • Information display: LED film screen can release public information such as notifications, guidelines, and data;
  • Decorative lighting: LED film screens have high transparency display effects, enhancing the visual hierarchy of buildings or spaces through dynamic light and shadow effects;
  • Interactive experience: LED display combined with touch or sensing technology enables interaction between people and screens (such as window display interactive advertising)
LED film screen parameters:
Model P3.75 P5 P6 P8 P10 P15 P20 P30
Pixel pitch 3.75*3.75mm 5*5mm 6.25*6mm 8.125*8mm 10*10mm 15*15mm 20*20mm 30*30mm
Pixel density 71,111 Pixels/m² 40000 Pixels/m² 26,560 Pixels/m² 15,375 Pixels/m² 10,000 Pixels/m² 4444 Pixels/m² 2500 Pixels/m² 1,111 Pixels/m²
Module Resolution 144×64Pixel 144×48Pixel 160×40Pixel 123×30Pixel 100×24Pixel 64×16Pixel 50×12Pixel 32×8Pixel
Module size
(W*H*T)

540mm

*240mm
*2mm

720mm

*240mm
*2mm

1000mm

*240mm
*2mm

1000mm

*240mm
*2mm

1000mm

*240mm
*2mm

960mm

*240mm
*2mm

1000mm

*240mm
*2mm

960mm*

240mm
*2mm

Weight/pcs 0.18Kg 0.2Kg 0.3Kg 0.3Kg 0.3Kg 0.3Kg 0.3Kg 0.3Kg
Installation method Glass direct/clamp tempered glass inner/inner arc installation
Brightness 1500-2000/3500-4000cd/m²
H/v viewing angle 140°/140°
Evenness ≥98%
Highest contrast ratio 4,000:1
Protection level IP43
Colour 16bit
Refresh rate ≥3,840Hz
Change frame frequency 60Frame /Second Suppot High Resolution3D:120Frame
Screen color temperature 2,000K~9,500K /Adjustable
Interface Windows
Working voltage AC:110V~240V,50~60Hz
Peak power ≤160W/m²
Average power 50W/m²~60W/m²
Continuous working hours ≥7×24h
Mean time between failures ≥100,000h
Screen temperature rise ≤3°(during use)
Operating ambient
temperature
-10~60℃
Operating environment
humidity
10%~90%RH/No condensation
LED film screen Usage scenarios:
  • Building glass curtain wall LED transparent screen:
    The exterior glass of office buildings, commercial complexes, hotels, etc. serves as a giant outdoor advertising screen when powered on, and does not affect the transparency of the building after power failure.
  • Indoor glass LED film screen/storefront LED display screen:
    Shopping mall windows, exhibition hall glass partitions, and glass walls in banks/airports are used for product display or brand promotion, balancing lighting and display functions.
  • Curved LED Display Screen/Irregular LED Display Screen:
    Curved glass LED screens, cylindrical LED displays, and wavy LED screens are used to achieve flexible displays (such as irregular decorations in science museums and art centers).
  • LED film screen for temporary activity scenes:
    Exhibition LED film screens, press conference LED film screens, pop-up stores, etc., due to their convenient installation and disassembly, can quickly build temporary display walls to meet short-term display needs.

LED Transparent Film Screen Flexible Transparent LED Screen 1

LED Transparent Film Screen Flexible Transparent LED Screen 2

LED Transparent Film Screen Flexible Transparent LED Screen 3

LED Transparent Film Screen Flexible Transparent LED Screen 4

LED Transparent Film Screen Flexible Transparent LED Screen 5

LED Transparent Film Screen Flexible Transparent LED Screen 6

LED Transparent Film Screen Flexible Transparent LED Screen 7

LED Transparent Film Screen Flexible Transparent LED Screen 8

LED Transparent Film Screen Flexible Transparent LED Screen 9

LED Transparent Film Screen Flexible Transparent LED Screen 10

LED Transparent Film Screen Flexible Transparent LED Screen 11

LED Transparent Film Screen Flexible Transparent LED Screen 12
